| Dimension | Value |
|---|---|
| Rated flow Qn | 1010 l/min |
| Switching principle | 5/2 |
| Compressed air outlet | Base plate DIN ISO 15407-1 |
| Operating pressure min. | 3 bar |
| Maximum operating pressure | 10 bar |
| Operating voltage AC at 50 Hz | 110 V |
| Operating voltage AC at 60 Hz | 110 V |
| Voltage tolerance AC 50 Hz | -10% / +15% |
| Voltage tolerance AC 60 Hz | -10% / +15% |
| Manual auxiliary operation | Not latching |
| Electrical connection type | Plug |
| Electrical connection size | EN 175301-803, Form C |
| Actuation function | Single-sided actuated |
| Sealing principle | soft sealing |
| Pre-control | internal |
| Certificates | LABS-free |
| Standards | ISO 15407-1 |
| Pilot valve | 26 mm |
| Valve type | Slide valve, without overlap |
| Type of connection | Plate connection |
| Provision | With air spring return |
| Compressed air connection inlet | Base plate DIN ISO 15407-1 |
| Compressed air connection, venting | Base plate DIN ISO 15407-1 |
| Compressed air connection, pilot control input | Base plate DIN ISO 15407-1 |
| Compressed air connection, pre-control, venting | Base plate DIN ISO 15407-1 |
| Dimension | Value |
|---|---|
| Article authenticity | Original article |
| Article condition | New |
| Single weight | not available |
| Dimensions (L x W x H) | not available |
| Country of origin** | FR🇫🇷 |
| Customs goods number | 84812090 |
| GTIN | 3661475949170 |
| RoHS compliant | On request |
| Manufacturer | Aventics |
Access to the official manufacturer catalog for compatible spare parts and repair kits.
excl. VAT
|will be calculated in cart
Product | Details | Actuation function | Certificates | Compressed air connection inlet | Compressed air connection, pilot control input | Compressed air connection, pre-control, venting | Compressed air connection, venting | Compressed air outlet | DC power consumption | Electrical connection 2 number of poles | Electrical connection size | Electrical connection type | Execution | Holding power AC 50 Hz | Holding power AC 60 Hz | Manual auxiliary operation | Maximum control pressure | Maximum operating pressure | Minimum ambient temperature | Minimum control pressure | Operating pressure min. | Operating voltage AC at 50 Hz | Operating voltage AC at 60 Hz | Operating voltage DC | Pilot valve | Power consumption | Pre-control | Provision | Rated flow Qn | Sealing principle | Size | Standards | Switching power AC 50 Hz | Switching principle | Type of connection | Valve type | Voltage tolerance AC 50 Hz | Voltage tolerance AC 60 Hz | Voltage tolerance DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5763990220 | 2x3/2-way valve Series CD01-PA 5763990220 CD01 - 3/2CC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NC/NC | - | - | Notched | 10 bar | - | -15 °C | 2.5 bar | - | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763990620 | 2x3/2-way valve Series CD01-PA 5763990620 CD01 - 3/2CC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NC/NC | - | - | Not latching | 10 bar | - | -15 °C | 2.5 bar | - | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763995220 | 2x3/2-way valve Series CD01-PA 5763995220 CD01 - 3/2CC - 024AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NC | 2.2 VA | 1.85 VA | Notched | - | - | - | - | - | 24 V | 24 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 3 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763995270 | 2x3/2-way valve Series CD01-PA 5763995270 CD01 - 3/2CC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NC | 3 VA | 2.4 VA | Notched | - | - | - | - | - | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763995670 | 2x3/2-way valve Series CD01-PA 5763995670 CD01 - 3/2CC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NC | 3 VA | 2.4 VA | Not latching | - | - | - | - | - | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763995280 | 2x3/2-way valve Series CD01-PA 5763995280 CD01 - 3/2CC - 230AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NC | 2.3 VA | 2 VA | Notched | - | - | - | - | - | 230 V | 230 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 3.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763970220 | 2x3/2-way valve Series CD01-PA 5763970220 CD01 - 3/2OO - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NO/NO | - | - | Notched | 10 bar | - | -15 °C | 3 bar | 3 bar | - | - | 24 V | 26 mm | - | internal | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763970620 | 2x3/2-way valve Series CD01-PA 5763970620 CD01 - 3/2OO - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NO/NO | - | - | Not latching | 10 bar | - | -15 °C | 3 bar | 3 bar | - | - | 24 V | 26 mm | - | internal | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763975220 | 2x3/2-way valve Series CD01-PA 5763975220 CD01 - 3/2OO - 024AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NO/NO | 2.2 VA | 1.85 VA | Notched | - | - | - | - | 3 bar | 24 V | 24 V | - | 26 mm | - | internal | - | - | soft sealing | - | ISO 15407-1 | 3 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763975270 | 2x3/2-way valve Series CD01-PA 5763975270 CD01 - 3/2OO - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NO/NO | 3 VA | 2.4 VA | Notched | - | - | - | - | 3 bar | 110 V | 110 V | - | 26 mm | - | internal | - | - | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763975670 | 2x3/2-way valve Series CD01-PA 5763975670 CD01 - 3/2OO - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NO/NO | 3 VA | 2.4 VA | Not latching | - | - | - | - | 3 bar | 110 V | 110 V | - | 26 mm | - | internal | - | - | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763960220 | 2x3/2-way valve Series CD01-PA 5763960220 CD01 - 3/2OC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NO/NO | - | - | Notched | 10 bar | 16 bar | -15 °C | - | 0 bar | - | - | 24 V | 26 mm | - | External | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763960620 | 2x3/2-way valve Series CD01-PA 5763960620 CD01 - 3/2OC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NO/NO | - | - | Not latching | 10 bar | 16 bar | -15 °C | - | 0 bar | - | - | 24 V | 26 mm | - | External | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763965270 | 2x3/2-way valve Series CD01-PA 5763965270 CD01 - 3/2OC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NO/NO | 3 VA | 2.4 VA | Notched | - | 16 bar | - | - | 0 bar | 110 V | 110 V | - | 26 mm | - | External | - | - | soft sealing | - | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763965670 | 2x3/2-way valve Series CD01-PA 5763965670 CD01 - 3/2OC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NO/NO | 3 VA | 2.4 VA | Not latching | - | 16 bar | - | - | 0 bar | 110 V | 110 V | - | 26 mm | - | External | - | - | soft sealing | - | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763950220 | 2x3/2-way valve Series CD01-PA 5763950220 CD01 - 3/2OC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NC/NO | - | - | Notched | 10 bar | - | -15 °C | 2.5 bar | - | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763950620 | 2x3/2-way valve Series CD01-PA 5763950620 CD01 - 3/2OC - 024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | NC/NO | - | - | Not latching | 10 bar | - | -15 °C | 2.5 bar | - | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763955270 | 2x3/2-way valve Series CD01-PA 5763955270 CD01 - 3/2OC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NO | 3 VA | 2.4 VA | Notched | - | - | - | - | - | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763955670 | 2x3/2-way valve Series CD01-PA 5763955670 CD01 - 3/2OC - 110AC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | NC/NO | 3 VA | 2.4 VA | Not latching | - | - | - | - | - | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | 4.2 VA | 2x3/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763990720 | 2x3/2-way valve Series CD01-PA 5763990720 CD01-3/2CC-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NC/NC | - | - | Not latching | - | 10 bar | - | - | 2.5 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763990520 | 2x3/2-way valve Series CD01-PA 5763990520 CD01-3/2CC-VD01-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NC/NC | - | - | Notched | - | 10 bar | - | - | 2.5 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763960720 | 2x3/2-way valve Series CD01-PA 5763960720 CD01-3/2 OC-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NO/NO | - | - | Not latching | 10 bar | 16 bar | - | - | 0 bar | - | - | 24 V | 26 mm | - | External | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763960520 | 2x3/2-way valve Series CD01-PA 5763960520 CD01-3/2OC-VD01-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NO/NO | - | - | Notched | 10 bar | 16 bar | - | - | 0 bar | - | - | 24 V | 26 mm | - | External | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763970720 | 2x3/2-way valve Series CD01-PA 5763970720 CD01-3/2 OO-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NO/NO | - | - | Not latching | - | 10 bar | - | 3 bar | 3 bar | - | - | 24 V | 26 mm | - | internal | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763970520 | 2x3/2-way valve Series CD01-PA 5763970520 CD01-3/2OO-VD01-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NO/NO | - | - | Notched | - | 10 bar | - | 3 bar | 3 bar | - | - | 24 V | 26 mm | - | internal | - | - | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763950720 | 2x3/2-way valve Series CD01-PA 5763950720 CD01-3/2 OC-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NC/NO | - | - | Not latching | - | 10 bar | - | - | 2.5 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763950520 | 2x3/2-way valve Series CD01-PA 5763950520 CD01-3/2OC-VD01-024DC | - | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | 4-pole | M12x1 | Plug | NC/NO | - | - | Notched | - | 10 bar | - | - | 2.5 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 2x3/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763510210 | 5/2-way valve Series CD01-PA 5763510210 CD01 - 5/2AR - 012DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | - | 3 bar | - | - | 12 V | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763510220 | 5/2-way valve Series CD01-PA 5763510220 CD01 - 5/2AS - 024DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | - | 3 bar | - | - | 24 V | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763510620 | 5/2-way valve Series CD01-PA 5763510620 CD01 - 5/2AS - 024DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 10 bar | - | - | 3 bar | - | - | 24 V | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763510920 | 5/2-way valve Series CD01-PA 5763510920 CD01 - 5/2AS - 024DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 2.06 W | - | EN 175301-803, Form C | Plug | - | - | - | - | - | 16 bar | - | - | 2 bar | - | - | 24 V | 26 mm | Low power consumption | internal | With air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763515220 | 5/2-way valve Series CD01-PA 5763515220 CD01 - 5/2AS - 024AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | - | 3 bar | 24 V | 24 V | - | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763515270 | 5/2-way valve Series CD01-PA 5763515270 CD01 - 5/2AS - 110AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | - | 3 bar | 110 V | 110 V | - | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763515670 | 5/2-way valve Series CD01-PA 5763515670 CD01 - 5/2AS - 110AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 10 bar | - | - | 3 bar | 110 V | 110 V | - | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763515280 | 5/2-way valve Series CD01-PA 5763515280 CD01 - 5/2AS - 230AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | - | 3 bar | 230 V | 230 V | - | 26 mm | - | internal | With air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763600220 | 5/2-way valve Series CD01-PA 5763600220 CD01 - 5/2SR - 024DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 16 bar | - | - | 0 bar | - | - | 24 V | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763600620 | 5/2-way valve Series CD01-PA 5763600620 CD01 - 5/2SR - 024DC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 16 bar | - | - | 0 bar | - | - | 24 V | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763605220 | 5/2-way valve Series CD01-PA 5763605220 CD01 - 5/2SR - 024AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 16 bar | - | - | 0 bar | 24 V | 24 V | - | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763605270 | 5/2-way valve Series CD01-PA 5763605270 CD01 - 5/2SR - 110AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 16 bar | - | - | 0 bar | 110 V | 110 V | - | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763605670 | 5/2-way valve Series CD01-PA 5763605670 CD01 - 5/2SR - 110AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 16 bar | - | - | 0 bar | 110 V | 110 V | - | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763605280 | 5/2-way valve Series CD01-PA 5763605280 CD01 - 5/2SR - 230AC | Single-sided actuated | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 16 bar | - | - | 0 bar | 230 V | 230 V | - | 26 mm | - | External | With spring/air spring return | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763520220 | 5/2-way valve Series CD01-PA 5763520220 CD01 - 5/2DS - 024DC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 10 bar | - | 2 bar | 2 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763520620 | 5/2-way valve Series CD01-PA 5763520620 CD01 - 5/2DS - 024DC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 10 bar | - | 2 bar | 2 bar | - | - | 24 V | 26 mm | - | internal | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763525220 | 5/2-way valve Series CD01-PA 5763525220 CD01 - 5/2DS - 024AC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | 2.2 VA | - | Notched | - | 10 bar | - | - | 2 bar | 24 V | 24 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763525270 | 5/2-way valve Series CD01-PA 5763525270 CD01 - 5/2DS - 110AC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | 3 VA | - | Notched | - | 10 bar | - | - | 2 bar | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763525670 | 5/2-way valve Series CD01-PA 5763525670 CD01 - 5/2DS - 110AC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | 3 VA | - | Not latching | - | 10 bar | - | - | 2 bar | 110 V | 110 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763525280 | 5/2-way valve Series CD01-PA 5763525280 CD01 - 5/2DS - 230AC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | 2.3 VA | - | Notched | - | 10 bar | - | - | 2 bar | 230 V | 230 V | - | 26 mm | - | internal | - | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
| 5763650220 | 5/2-way valve Series CD01-PA 5763650220 CD01 - 5/2DS - 024DC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Notched | - | 16 bar | - | 2 bar | -0.95 bar | - | - | 24 V | 26 mm | - | External | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763650620 | 5/2-way valve Series CD01-PA 5763650620 CD01 - 5/2DS - 024DC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | 1.6 W | - | EN 175301-803, Form C | Plug | - | - | - | Not latching | - | 16 bar | - | 2 bar | -0.95 bar | - | - | 24 V | 26 mm | - | External | - | 1010 l/min | soft sealing | 26 mm | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | - | - | -10% / +10% |
| 5763655270 | 5/2-way valve Series CD01-PA 5763655270 CD01 - 5/2DS - 110AC | Double-acting | LABS-free | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | Base plate DIN ISO 15407-1 | - | - | EN 175301-803, Form C | Plug | - | 3 VA | - | Notched | - | 16 bar | - | - | -0.95 bar | 110 V | 110 V | - | 26 mm | - | External | - | 1010 l/min | soft sealing | - | ISO 15407-1 | - | 5/2 | Plate connection | Slide valve, without overlap | -10% / +15% | -10% / +15% | - |
