| Dimension | Value |
|---|---|
| Article authenticity | Original article |
| Article condition | New |
| Single weight | not available |
| Dimensions (L x W x H) | not available |
| Country of origin** | On request |
| Customs goods number | 84129080 |
| GTIN | On request |
| RoHS compliant | On request |
| Manufacturer | Aventics |
Access to the official manufacturer catalog for compatible spare parts and repair kits.
| Dimension | Value |
|---|---|
| Standards | Based on ISO 21287 |
| Piston diameter | 50 mm |
| Hub | 20 mm |
| Connections | G 1/8 |
| Principle of operation | single-acting, pressureless extended |
| Damping | Elastic damping |
| Magnetic piston | Piston with magnet |
| Cylinder peculiarities | Pin configuration |
| Pressure for determining piston forces | 6,3 bar |
| Piston force retracting | 730 N |
| Piston force extending | 1237 N |
| Minimum ambient temperature | -20 °C |
| Maximum ambient temperature | 80 °C |
| Operating pressure min. | 2 bar |
| Maximum operating pressure | 10 bar |
| Maximum spring force | 82 N |
| Max. permissible radial bearing load | 6280 N |
| Permissible radial force F during switching | 1500 N |
| Medium | Compressed air |
| Medium temperature min. | -20 °C |
| Maximum medium temperature | 80 °C |
| Max. particle size | 50 µm |
| Maximum oil content in compressed air | 5 mg/m³ |
| Piston rod | Stainless steel |
| Material front cover | Aluminum |
Product | Details | Connections | Cylinder peculiarities | Damping | Hub | Magnetic piston | Material front cover | Max. particle size | Max. permissible radial bearing load | Maximum ambient temperature | Maximum medium temperature | Maximum oil content in compressed air | Maximum operating pressure | Maximum spring force | Medium | Medium temperature min. | Minimum ambient temperature | Operating pressure min. | Permissible radial force F during switching | Piston diameter | Piston force extending | Piston force retracting | Piston rod | Pressure for determining piston forces | Principle of operation | Standards |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| R452000672 | Compact cylinder Series CCI-SC R452000672 CCI-DS-050-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000675 | Compact cylinder Series CCI-SC R452000675 CCI-DS-050-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000678 | Compact cylinder Series CCI-SC R452000678 CCI-DS-050-30-ST-TR | G 1/8 | Pin configuration | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000674 | Compact cylinder Series CCI-SC R452000674 CCI-DS-050-20-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000677 | Compact cylinder Series CCI-SC R452000677 CCI-DS-050-25-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000680 | Compact cylinder Series CCI-SC R452000680 CCI-DS-050-30-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000656 | Compact cylinder Series CCI-SC R452000656 CCI-DA-050-20-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000659 | Compact cylinder Series CCI-SC R452000659 CCI-DA-050-25-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000662 | Compact cylinder Series CCI-SC R452000662 CCI-DA-050-30-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000655 | Compact cylinder Series CCI-SC R452000655 CCI-DA-050-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000658 | Compact cylinder Series CCI-SC R452000658 CCI-DA-050-25-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000661 | Compact cylinder Series CCI-SC R452000661 CCI-DA-050-30-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000638 | Compact cylinder Series CCI-SC R452000638 CCI-SA-050-20-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000641 | Compact cylinder Series CCI-SC R452000641 CCI-SA-050-25-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000644 | Compact cylinder Series CCI-SC R452000644 CCI-SA-050-30-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 5000 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1200 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000627 | Compact cylinder Series CCI-SC R452000627 CCI-SA-032-15-ST-TR | G 1/8 | Pin configuration | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000630 | Compact cylinder Series CCI-SC R452000630 CCI-SA-032-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000633 | Compact cylinder Series CCI-SC R452000633 CCI-SA-032-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000636 | Compact cylinder Series CCI-SC R452000636 CCI-SA-050-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000639 | Compact cylinder Series CCI-SC R452000639 CCI-SA-050-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000642 | Compact cylinder Series CCI-SC R452000642 CCI-SA-050-30-ST-TR | G 1/8 | Pin configuration | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000645 | Compact cylinder Series CCI-SC R452000645 CCI-DA-032-15-ST-TR | G 1/8 | Pin configuration | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000648 | Compact cylinder Series CCI-SC R452000648 CCI-DA-032-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000651 | Compact cylinder Series CCI-SC R452000651 CCI-DA-032-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000654 | Compact cylinder Series CCI-SC R452000654 CCI-DA-050-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000657 | Compact cylinder Series CCI-SC R452000657 CCI-DA-050-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000660 | Compact cylinder Series CCI-SC R452000660 CCI-DA-050-30-ST-TR | G 1/8 | Pin configuration | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000628 | Compact cylinder Series CCI-SC R452000628 CCI-SA-032-15-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000631 | Compact cylinder Series CCI-SC R452000631 CCI-SA-032-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000634 | Compact cylinder Series CCI-SC R452000634 CCI-SA-032-25-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000637 | Compact cylinder Series CCI-SC R452000637 CCI-SA-050-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000640 | Compact cylinder Series CCI-SC R452000640 CCI-SA-050-25-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000643 | Compact cylinder Series CCI-SC R452000643 CCI-SA-050-30-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | single-acting, pressureless extended | Based on ISO 21287 |
| R452000664 | Compact cylinder Series CCI-SC R452000664 CCI-DS-032-15-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000667 | Compact cylinder Series CCI-SC R452000667 CCI-DS-032-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000670 | Compact cylinder Series CCI-SC R452000670 CCI-DS-032-25-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000673 | Compact cylinder Series CCI-SC R452000673 CCI-DS-050-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000676 | Compact cylinder Series CCI-SC R452000676 CCI-DS-050-25-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000679 | Compact cylinder Series CCI-SC R452000679 CCI-DS-050-30-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 30 mm | Piston with magnet | Aluminum | 50 µm | 6280 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 82 N | Compressed air | -20 °C | -20 °C | 2 bar | 1500 N | 50 mm | 1237 N | 730 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000663 | Compact cylinder Series CCI-SC R452000663 CCI-DS-032-15-ST-TR | G 1/8 | Pin configuration | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000666 | Compact cylinder Series CCI-SC R452000666 CCI-DS-032-20-ST-TR | G 1/8 | Pin configuration | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000669 | Compact cylinder Series CCI-SC R452000669 CCI-DS-032-25-ST-TR | G 1/8 | Pin configuration | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 3270 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000665 | Compact cylinder Series CCI-SC R452000665 CCI-DS-032-15-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000668 | Compact cylinder Series CCI-SC R452000668 CCI-DS-032-20-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000671 | Compact cylinder Series CCI-SC R452000671 CCI-DS-032-25-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting with spring return, pressureless extended | Based on ISO 21287 |
| R452000647 | Compact cylinder Series CCI-SC R452000647 CCI-DA-032-15-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000650 | Compact cylinder Series CCI-SC R452000650 CCI-DA-032-20-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000653 | Compact cylinder Series CCI-SC R452000653 CCI-DA-032-25-ST-RO | G 1/8 | Roller execution, twist-proof | Elastic damping | 25 mm | Piston with magnet | Aluminum | 50 µm | 2670 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 420 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000646 | Compact cylinder Series CCI-SC R452000646 CCI-DA-032-15-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 15 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
| R452000649 | Compact cylinder Series CCI-SC R452000649 CCI-DA-032-20-ST-NR | G 1/8 | Pin configuration, torsionally secured | Elastic damping | 20 mm | Piston with magnet | Aluminum | 50 µm | 3720 N | 80 °C | 80 °C | 5 mg/m³ | 10 bar | 35 N | Compressed air | -20 °C | -20 °C | 2 bar | 570 N | 32 mm | 507 N | 309 N | Stainless steel | 6,3 bar | Double-acting | Based on ISO 21287 |
