| Dimension | Value |
|---|---|
| Article authenticity | Original article |
| Article condition | New |
| Single weight | 38,00 kg |
| Dimensions (L x W x H) | not available |
| Country of origin** | US🇺🇸 |
| Customs goods number | 84135061 |
| GTIN | On request |
| RoHS compliant | On request |
| Manufacturer | Enerpac |
| Dimension | Value |
|---|---|
| type | Hydraulic Pump |
| Subtypes | Electric pump - Torque wrench |
| Series | TQ |
| Compatible products | S1500X S1500PX S3000X S3000PX S6000X S6000PX S11000X S11000PX S25000X S25000PX W2000X W2000X W4000X W4000X W8000X W8000X W15000X W15000X W22000X W22000X W35000X W35000X RSL1500 RSL3000 RSL5000 RSL8000 RSL11000 RSL19000 RSL28000 DSX1500 DSX3000 DSX5000 DSX11000 DSX25000 HMT1500 HMT3500 HMT7500 HMT13000 |
| Maximum operating pressure in bar | 700 |
| Maximum operating pressure in psi | 10,000 |
| Maximum delivery volume at nominal pressure | 0.5 l/min |
| Tank content (cm3) | 4000 |
| Usable oil volume (liters) | 4,0 |
| Maximum Flow at Rated Pressure (litres) | 0.5 |
| Noise level (dBA) | 82 - 85 |
| Motor voltage | 208-240 V |
| Motor phases | 1 phase |
| Motor hertz | 50 Hz |
| Areas of maximum operating pressure (psi) | 10,000 |
| Reservoir size ranges (in gallons) | 1 - 1.99 |
| Areas of maximum operating pressure (bar) | 700 |
| Maximum delivery volume at nominal pressure | 0.5 l/min |
| Valve operation | Electromagnet |
| Valve type | 4/2-way valve |
| Motor Technical Data | 230 V, 1 phase, 50 Hz |
| For the following torque wrenches | All S and W series |
| Reservoir Capacity (inches3) | 231 |
| Reservoir capacity (gallon) | 1 |
| Usable oil capacity (gallon) | 1 |
| Type of drive | Electric |
| Maximum flow rate ranges at rated pressure (l/min) | 0,35 - 0,64 |
Product | Details | Areas of maximum operating pressure (bar) | Areas of maximum operating pressure (psi) | Compatible products | For the following torque wrenches | Maximum delivery volume at nominal pressure | Maximum Flow at Rated Pressure (litres) | Maximum flow rate ranges at rated pressure (l/min) | Maximum operating pressure in bar | Maximum operating pressure in psi | Motor hertz | Motor phases | Motor Technical Data | Motor voltage | Noise level (dBA) | Reservoir capacity (gallon) | Reservoir Capacity (inches3) | Reservoir size ranges (in gallons) | Series | Subtypes | Tank content (cm3) | type | Type of drive | Usable oil capacity (gallon) | Usable oil volume (liters) | Valve operation | Valve type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TQ700B | Electric pump - Torque wrench | 700 | 10,000 | S1500X, S1500PX, S3000X, S3000PX, S6000X, S6000PX, S11000X, S11000PX, S25000X, S25000PX, W2000X, W2000X, W4000X, W4000X, W8000X, W8000X, W15000X, W15000X, W22000X, W22000X, W35000X, W35000X, RSL1500, RSL3000, RSL5000, RSL8000, RSL11000, RSL19000, RSL28000, DSX1500, DSX3000, DSX5000, DSX11000, DSX25000, HMT1500, HMT3500, HMT7500, HMT13000 | All S and W series | 0.5 l/min | 0.5 | 0,35 - 0,64 | 700 | 10,000 | 50/60 Hz | 1 phase | 115 V, 1 phase, 50/60 Hz | 115 V | 82 - 85 | 1 | 231 | 1 - 1.99 | TQ | Electric pump - Torque wrench | 4000 | Hydraulic Pump | Electric | 1 | 4,0 | Electromagnet | 4/2-way valve |
| TQ700E | Electric pump - Torque wrench | 700 | 10,000 | S1500X, S1500PX, S3000X, S3000PX, S6000X, S6000PX, S11000X, S11000PX, S25000X, S25000PX, W2000X, W2000X, W4000X, W4000X, W8000X, W8000X, W15000X, W15000X, W22000X, W22000X, W35000X, W35000X, RSL1500, RSL3000, RSL5000, RSL8000, RSL11000, RSL19000, RSL28000, DSX1500, DSX3000, DSX5000, DSX11000, DSX25000, HMT1500, HMT3500, HMT7500, HMT13000 | All S and W series | 0.5 l/min | 0.5 | 0,35 - 0,64 | 700 | 10,000 | 50 Hz | 1 phase | 230 V, 1 phase, 50 Hz | 208-240 V | 82 - 85 | 1 | 231 | 1 - 1.99 | TQ | Electric pump - Torque wrench | 4000 | Hydraulic Pump | Electric | 1 | 4,0 | Electromagnet | 4/2-way valve |
| TQ700I | Electric pump - Torque wrench | 700 | 10,000 | S1500X, S1500PX, S3000X, S3000PX, S6000X, S6000PX, S11000X, S11000PX, S25000X, S25000PX, W2000X, W2000X, W4000X, W4000X, W8000X, W8000X, W15000X, W15000X, W22000X, W22000X, W35000X, W35000X, RSL1500, RSL3000, RSL5000, RSL8000, RSL11000, RSL19000, RSL28000, DSX1500, DSX3000, DSX5000, DSX11000, DSX25000, HMT1500, HMT3500, HMT7500, HMT13000 | All S and W series | 0.5 l/min | 0.5 | 0,35 - 0,64 | 700 | 10,000 | 60 Hz | 1 phase | 230 V, 1 phase, 60 Hz | 208-240 V | 82 - 85 | 1 | 231 | 1 - 1.99 | TQ | Electric pump - Torque wrench | 4000 | Hydraulic Pump | Electric | 1 | 4,0 | Electromagnet | 4/2-way valve |
