| Dimension | Value |
|---|---|
| type | Hydraulic Pump |
| Subtypes | Electric pump - Economy |
| Series | PU |
| Maximum operating pressure in bar | 700 |
| Maximum operating pressure in psi | 10,000 |
| Maximum delivery volume at nominal pressure | 0.32 l/min |
| Maximum delivery volume at nominal pressure | 20 in³/min |
| Tank content (cm3) | 3800 |
| Duty Cycle | Intermittent |
| Usable oil volume (liters) | 3,8 |
| Maximum Flow at Rated Pressure (in3) | 20 |
| Maximum Flow at Rated Pressure (litres) | 0.32 |
| Pressure rate (psi) 2nd stage | 10,000 |
| Pressure rate (psi) 1st stage | 200 |
| Noise level (dBA) | 85 |
| Current (A) | 9.5 |
| Maximum operating pressure 1st stage (bar) | 13 |
| Maximum operating pressure 2 stage (bar) | 700 |
| Motor voltage | 208-240 V |
| Areas of maximum operating pressure (bar) | 700 |
| Maximum delivery volume at nominal pressure | 0.32 l/min |
| Pump control | Remote control |
| Valve function | Extend / Stop / Retract |
| Valve operation | Electromagnet |
| Valve type | 3/2-way valve |
| Operation of the pump | Drain valve and stop |
| Motor Technical Data | 230 V |
| Reservoir Capacity (inches3) | 231 |
| Usable oil capacity (gallon) | 1 |
| Motor power (Hp) | 0.5 |
| Type of drive | Electric |
| Cylinder compatibility | Single-acting |
| Dimension E (inches) | 5.12 |
| Output flow rate 1st stage in 3 min | 200 |
| Dimension F (mm) | 323 |
| Dimension D (inches) | 4.15 |
| Dimension C (inches) | 14.72 |
| Dimension E (mm) | 130 |
| Dimension B (inches) | 12.18 |
| Output flow rate 2nd stage (l/min) | 0,32 |
| Dimension D (mm) | 105 |
| OutputFlowRate2ndStageIn3min | 20 |
| Dimension J (mm) | 142 |
| Dimension H (inches) | 0.4 |
| Dimension F (inches) | 12.74 |
| Maximum flow rate ranges at rated pressure in 3 min | 0 - 20 |
| Output flow rate 1st stage (l/min) | 3,31 |
| Dimension J (inches) | 5.62 |
| Dimension A (inches) | 14.5 |
| Maximum flow rate ranges at rated pressure (l/min) | 0 - 0,34 |
| Dimension C (mm) | 373 |
| Dimension B (mm) | 309 |
| Dimension A (mm) | 368 |
| Dimension | Value |
|---|---|
| Article authenticity | Original article |
| Article condition | New |
| Single weight | 17,62 kg |
| Dimensions (L x W x H) | not available |
| Country of origin** | US🇺🇸 |
| Customs goods number | 84135061 |
| GTIN | On request |
| RoHS compliant | On request |
| Manufacturer | Enerpac |
excl. VAT
|will be calculated in cart
Product | Details | Areas of maximum operating pressure (bar) | Areas of maximum operating pressure (psi) | Current (A) | Cylinder compatibility | Dimension A (inches) | Dimension A (mm) | Dimension B (inches) | Dimension B (mm) | Dimension C (inches) | Dimension C (mm) | Dimension D (inches) | Dimension D (mm) | Dimension E (inches) | Dimension E (mm) | Dimension F (inches) | Dimension F (mm) | Dimension H (inches) | Dimension J (inches) | Dimension J (mm) | Duty Cycle | Maximum delivery volume at nominal pressure | Maximum Flow at Rated Pressure (in3) | Maximum Flow at Rated Pressure (litres) | Maximum flow rate ranges at rated pressure (l/min) | Maximum flow rate ranges at rated pressure in 3 min | Maximum operating pressure 1st stage (bar) | Maximum operating pressure 2 stage (bar) | Maximum operating pressure in bar | Maximum operating pressure in psi | Motor power (Hp) | Motor Technical Data | Motor voltage | Noise level (dBA) | Operation of the pump | Output flow rate 1st stage (l/min) | Output flow rate 1st stage in 3 min | Output flow rate 2nd stage (l/min) | OutputFlowRate2ndStageIn3min | Pressure rate (psi) 1st stage | Pressure rate (psi) 2nd stage | Pump control | Reservoir Capacity (inches3) | Series | Subtypes | Tank content (cm3) | type | Type of drive | Usable oil capacity (gallon) | Usable oil volume (liters) | Valve function | Valve operation | Valve type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PUD1100E | Electric pump - Economy | 700 | 10,000 | 9.5 | Single-acting | 9.62 | 244 | 9.62 | 244 | 14.25 | 362 | 4 | 101 | 4.72 | 119 | 8 | 203 | 0.4 | 5.25 | 133 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | Drain valve | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 116 | PU | Electric pump - Economy | 1900 | Hydraulic Pump | Electric | 0.5 | 1,9 | Extend / Retract | - | - |
| PUD1101E | Electric pump - Economy | 700 | 10,000 | 9.5 | Single-acting | 14.5 | 368 | 12.18 | 309 | 14.72 | 373 | 4.15 | 105 | 5.12 | 130 | 12.74 | 323 | 0.4 | 5.62 | 142 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | Drain valve | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 231 | PU | Electric pump - Economy | 3800 | Hydraulic Pump | Electric | 1 | 3,8 | Extend / Retract | - | - |
| PUD1300E | Electric pump - Economy | 700 | - | 9.5 | Single-acting | 9.62 | 244 | 9.62 | 244 | 14.25 | 362 | 4 | 101 | 4.72 | 119 | 8 | 203 | 0.4 | 5.25 | 133 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | Drain valve and stop | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 116 | PU | Electric pump - Economy | 1900 | Hydraulic Pump | Electric | 0.5 | 1,9 | Extend / Stop / Retract | Electromagnet | 3/2-way valve |
| PUD1301E | Electric pump - Economy | 700 | - | 9.5 | Single-acting | 14.5 | 368 | 12.18 | 309 | 14.72 | 373 | 4.15 | 105 | 5.12 | 130 | 12.74 | 323 | 0.4 | 5.62 | 142 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | Drain valve and stop | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 231 | PU | Electric pump - Economy | 3800 | Hydraulic Pump | Electric | 1 | 3,8 | Extend / Stop / Retract | Electromagnet | 3/2-way valve |
| PUJ1200E | Electric pump - Economy | 700 | 10,000 | 9.5 | Single-acting | 9.62 | 244 | 9.62 | 244 | 14.25 | 362 | 4 | 101 | 4.72 | 119 | 8 | 203 | 0.4 | 5.25 | 133 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 116 | PU | Electric pump - Economy | 1900 | Hydraulic Pump | Electric | 0.5 | 1,9 | Extend / Stop / Retract | Manual | 3/2-way valve |
| PUJ1201E | Electric pump - Economy | 700 | 10,000 | 9.5 | Single-acting | 14.5 | 368 | 12.18 | 309 | 14.72 | 373 | 4.15 | 105 | 5.12 | 130 | 12.74 | 323 | 0.4 | 5.62 | 142 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 231 | PU | Electric pump - Economy | 3800 | Hydraulic Pump | Electric | 1 | 3,8 | Extend / Stop / Retract | Manual | 3/2-way valve |
| PUJ1400E | Electric pump - Economy | 700 | 10,000 | 9.5 | Double-acting | 9.62 | 244 | 9.62 | 244 | 14.25 | 362 | 4 | 101 | 4.72 | 119 | 8 | 203 | 0.4 | 5.25 | 133 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 116 | PU | Electric pump - Economy | 1900 | Hydraulic Pump | Electric | 0.5 | 1,9 | Extend / Stop / Retract | Manual | 4/3-way valve |
| PUJ1401E | Electric pump - Economy | 700 | 10,000 | 9.5 | Double-acting | 14.5 | 368 | 12.18 | 309 | 14.72 | 373 | 4.15 | 105 | 5.12 | 130 | 12.74 | 323 | 0.4 | 5.62 | 142 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 230 V | 208-240 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 231 | PU | Electric pump - Economy | 3800 | Hydraulic Pump | Electric | 1 | 3,8 | Extend / Stop / Retract | Manual | 4/3-way valve |
| PUJ1400B | Electric pump - Economy | 700 | 10,000 | 9.5 | Double-acting | 9.62 | 244 | 9.62 | 244 | 14.25 | 362 | 4 | 101 | 4.72 | 119 | 8 | 203 | 0.4 | 5.25 | 133 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 115 V | 115 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 116 | PU | Electric pump - Economy | 1900 | Hydraulic Pump | Electric | 0.5 | 1,9 | Extend / Stop / Retract | Manual | 4/3-way valve |
| PUJ1401B | Electric pump - Economy | 700 | 10,000 | 9.5 | Double-acting | 14.5 | 368 | 12.18 | 309 | 14.72 | 373 | 4.15 | 105 | 5.12 | 130 | 12.74 | 323 | 0.4 | 5.62 | 142 | Intermittent | 0.32 l/min | 20 | 0.32 | 0 - 0,34 | 0 - 20 | 13 | 700 | 700 | 10,000 | 0.5 | 115 V | 115 V | 85 | - | 3,31 | 200 | 0,32 | 20 | 200 | 10,000 | Remote control | 231 | PU | Electric pump - Economy | 3800 | Hydraulic Pump | Electric | 1 | 3,8 | Extend / Stop / Retract | Manual | 4/3-way valve |
