| Dimension | Value |
|---|---|
| Article authenticity | Original article |
| Article condition | New |
| Single weight | 80,40 kg |
| Dimensions (L x W x H) | not available |
| Country of origin** | US🇺🇸 |
| Customs goods number | 84135061 |
| GTIN | On request |
| RoHS compliant | On request |
| Manufacturer | Enerpac |
| Dimension | Value |
|---|---|
| type | Hydraulic Pump |
| Subtypes | Electric pump - Torque wrench |
| Series | ZE5T |
| Maximum operating pressure in bar | 700 |
| Maximum operating pressure in psi | 10,000 |
| Maximum delivery volume at nominal pressure | 1.6 l/min |
| Maximum delivery volume at nominal pressure | 120 in³/min |
| Tank content (cm3) | 8000 |
| Duty Cycle | Extended |
| Overpressure valve adjustment range (psi) | 1,000 - 11,600 |
| Usable oil volume (liters) | 8,0 |
| Maximum Flow at Rated Pressure (in3) | 120 |
| Maximum Flow at Rated Pressure (litres) | 1.6 |
| Noise level (dBA) | 75 |
| Setting of the pressure limiting valve (bar) | 70 - 800 |
| Motor voltage | 380-415 V |
| Motor phases | 3 phase |
| Motor hertz | 50/60 Hz |
| Areas of maximum operating pressure (psi) | 10,000 |
| Areas of maximum operating pressure (bar) | 700 |
| Maximum delivery volume at nominal pressure | 1.6 l/min |
| Valve operation | Electromagnet |
| Valve type | 3-way, 2-position |
| Motor Technical Data | 400 V, 3 Ph, 50/60 Hz |
| For the following torque wrenches | All S and W series |
| Reservoir Capacity (inches3) | 416 |
| Usable oil capacity (gallon) | 2 |
| Motor power (rpm) | 1750 |
| Motor power (Hp) | 3 |
| Valve model | VM32 |
| Type of drive | Electric |
| OutputFlowRate at 50 bar (l/min) | 11,2 |
| Output flow rate at 7 bar in 3 minutes | 11,8 |
| Output flow rate at 100 psi in 3 minutes | 850 |
| Output flow rate 700 bar in 3 minutes | 1,6 |
| Output flow rate at 7 bar (l/min) | 11,8 |
| Output Flow Rate 10000 Psi In3/min | 120 |
| Maximum flow rate ranges at rated pressure in 3 min | 120 - 200 |
| OutputFlowRate700PsiIn3min | 825 |
| Output Flow Rate 700 bar l/min | 1,6 |
| OutputFlowRate5000PsiIn3min | 123 |
| Maximum flow rate ranges at rated pressure (l/min) | 0,98 - 1,95 |
| Output Flow Rate 350 bar l/min | 1,7 |
| Output flow rate at 50 bar in 3 minutes | 11,2 |
| OutputFlowRate350barIn3min | 1,7 |
Product | Details | Areas of maximum operating pressure (bar) | Areas of maximum operating pressure (psi) | Duty Cycle | For the following torque wrenches | Maximum delivery volume at nominal pressure | Maximum Flow at Rated Pressure (in3) | Maximum Flow at Rated Pressure (litres) | Maximum flow rate ranges at rated pressure (l/min) | Maximum flow rate ranges at rated pressure in 3 min | Maximum operating pressure in bar | Maximum operating pressure in psi | Motor hertz | Motor phases | Motor power (Hp) | Motor power (kW) | Motor power (rpm) | Motor Technical Data | Motor voltage | Noise level (dBA) | Output Flow Rate 10000 Psi In3/min | Output Flow Rate 350 bar l/min | Output flow rate 700 bar in 3 minutes | Output Flow Rate 700 bar l/min | Output flow rate at 100 psi in 3 minutes | Output flow rate at 50 bar in 3 minutes | Output flow rate at 7 bar (l/min) | Output flow rate at 7 bar in 3 minutes | OutputFlowRate at 50 bar (l/min) | OutputFlowRate350barIn3min | OutputFlowRate5000PsiIn3min | OutputFlowRate700PsiIn3min | Overpressure valve adjustment range (psi) | Reservoir Capacity (inches3) | Series | Setting of the pressure limiting valve (bar) | Subtypes | Tank content (cm3) | type | Type of drive | Usable oil capacity (gallon) | Usable oil volume (liters) | Valve model | Valve operation | Valve type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ZE5204TW-QHR | Electric pump - Torque wrench | 700 | - | Extended | All S and W series | 1.6 l/min | - | 1.6 | 0,98 - 1,95 | - | 700 | - | 50/60 Hz | 3 phase | - | 2,2 | - | 400 V, 3 Ph, 50/60 Hz | 380-415 V | 75 | 120 | 1,7 | 1,6 | 1,6 | 850 | 11,2 | 11,8 | 11,8 | 11,2 | 1,7 | - | - | - | 277 | ZE5T | 70 - 800 | Electric pump - Torque wrench | 4000 | Hydraulic Pump | Electric | - | 4,0 | VM32 | Manual | 3/2-way valve |
| ZE5208TW-QHR | Electric pump - Torque wrench | 700 | 10,000 | Extended | All S and W series | 1.6 l/min | 120 | 1.6 | 0,98 - 1,95 | 120 - 200 | 700 | 10,000 | 50/60 Hz | 3 phase | 3 | - | 1750 | 400 V, 3 Ph, 50/60 Hz | 380-415 V | 75 | 120 | 1,7 | 1,6 | 1,6 | 850 | 11,2 | 11,8 | 11,8 | 11,2 | 1,7 | 123 | 825 | 1,000 - 11,600 | 416 | ZE5T | 70 - 800 | Electric pump - Torque wrench | 8000 | Hydraulic Pump | Electric | 2 | 8,0 | VM32 | Electromagnet | 3-way, 2-position |
