Enerpac Pressure Gauge

Name: Enerpac Pressure Gauge G2533SR
Brand: Enerpac
SKU: G2533SR
Price: 120.51 EUR
Availability: InStock

120,51 €

excl. VAT

143,41 € incl. VAT

Availability:

Shipping:

Free shippingwithin Germany|

Volume Pricing

Price / packaging unit (excl. VAT)

Found it cheaper elsewhere? Send us the offer as a link or PDF, we usually match it.

Packaging Unit:

1 piece

Quantity

or pay directly

We accept

Invoice

Prepayment

Support

Advice on selection, alternatives and availability

EmailCall WhatsApp

Mon - Fri from 8:00 AM - 6:00 PM

+49 39203 863988 (German & English)sales@partbase.com (all languages)

Featured in

Also via

Features for G2533SR from Enerpac

type: Gauge
Subtypes: Pressure gauge
Series: G
Maximum operating pressure in bar: 200
Maximum operating pressure in psi: 3,000
Minimum value (bar): 5
Largest value (bar): 50
Smallest value (psi): 50
Greatest value (psi): 500
Type of assembly: Back side
Accuracy in % of scale value: 1.5
Type: Glycerine Filled
Dimension G (mm): SAE No. 4
Dimension D (inches): 2.50
Dimension B (inches): 1.23
Dimension D (mm): 63
Dimension A (inches): 2.46
Dimension B (mm): 31
Thread: SAE No. 4
FaceDiameterMm: 63
Dimension G (inches): SAE No. 4
Dimension A (mm): 62

Documents

Brochure ES-LA
Download
Brochure EN-GB
Download
Brochure IT
Download
Brochure PT-BR
Download
Brochure EN-US
Download
Brochure DE
Download

Manufacturer article description

Accurate to ±1.5% of full scale. All pressure-sensitive parts are sealed and damped with glycerine to ensure a long service life. Including safety burst disc and pressure equalisation diaphragm. Copper-alloy Bourdon safety tube for 70 bar and above. Display in bar and psi, outside diameter: 63 mm

Further information for G2533SR from Enerpac

Article authenticity: Original article
Article condition: New
Single weight: 300 g
Dimensions (L x W x H): not available
Country of origin**: US🇺🇸
Customs goods number: 90262040
GTIN: On request
RoHS compliant: On request
Manufacturer: Enerpac

*:Delivery times are not binding and subject to change.

**:The origin information of the products is for orientation only. The actual origin may differ. This does not guarantee any benefits related to import advantages or availability from certain countries.

***:All product specifications, technical data and images are provided without warranty. Product images sometimes serve as symbolic images and may differ from the actual item.

Series Comparison for Enerpac G-Series

Product	Details	Accuracy in % of scale value	Dimension A (inches)	Dimension A (mm)	Dimension B (inches)	Dimension B (mm)	Dimension C (inches)	Dimension C (mm)	Dimension D (inches)	Dimension D (mm)	Dimension E (inches)	Dimension G (inches)	Dimension G (mm)	FaceDiameterMm	Greatest value (psi)	Largest value (bar)	Maximum operating pressure in bar	Maximum operating pressure in psi	Minimum value (bar)	Series	Smallest value (psi)	Subtypes	Thread	type	Type	Type of assembly
Enerpac G2509L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	10	1	7	100	0,01	G	2	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2510L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	10	1	11	160	0,02	G	2	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2511L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	50	1	14	200	0,02	G	5	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2512L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	50	5	20	300	0,50	G	5	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2513L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	100	10	40	600	1	G	10	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2514L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	100	10	70	1,000	1	G	20	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2515L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	500	10	140	2,000	2	G	50	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2516L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	500	50	200	3,000	5	G	50	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2517L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	1000	100	400	6,000	10	G	100	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2531R	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	-	63	2.48	-	1/4 NPTF	63	100	10	70	1,000	1	G	20	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Back, middle
Enerpac G2534R	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	-	63	2.48	-	1/4 NPTF	63	1000	100	400	6,000	10	G	100	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Back, middle
Enerpac G2535L	Pressure Gauge G2535L	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	2000	100	700	10,000	10	G	200	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2536L	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	3.31	84	-	-	1/4 NPTF	63	3000	100	1000	15,000	20	G	200	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2537R	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	-	63	2.48	-	1/4 NPTF	63	2000	100	700	10,000	10	G	200	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Back, middle
Enerpac G2538R	Pressure Gauge	1.5	2.5	63	1.46	37	1/4" NPTF	-	-	63	2.48	-	1/4 NPTF	63	3000	100	1000	15,000	20	G	200	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Back, middle
Enerpac G4039L	Pressure Gauge	1	4	100	1.93	49	1/2" NPTF	1/2 NPTF	5.38	136	-	-	-	100	1000	100	700	10,000	10	G	100	Pressure gauge	1/2 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G4040L	Pressure Gauge	1	4	100	1.93	49	1/2" NPTF	1/2 NPTF	5.38	136	-	-	-	100	3000	100	1000	15,000	20	G	200	Pressure gauge	1/2 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G4088L	Pressure Gauge	1	4	100	1.15	29	1/4" NPTF	1/4 NPTF	4.8	121	-	-	-	100	1000	100	700	10,000	10	G	100	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G4089L	Pressure Gauge	1	4	100	1.15	29	1/4" NPTF	1/4 NPTF	4.8	121	-	-	-	100	3000	100	1000	15,000	20	G	200	Pressure gauge	1/4 NPTF	Gauge	Glycerine Filled	Underside
Enerpac G2514SL	Pressure Gauge	-	-	93	-	31	-	-	-	63	-	SAE No. 4	SAE No. 4	-	100	10	70	1,000	1	G	20	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Underside
Enerpac G2516SL	Pressure Gauge	-	3.66	93	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	-	500	50	200	3,000	5	G	50	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Underside
Enerpac G2517SL	Pressure Gauge	-	3.66	93	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	-	1000	100	400	6,000	10	G	100	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Underside
Enerpac G2531SR	Pressure Gauge	1.5	2.46	62	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	63	100	10	70	1,000	1	G	20	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Back side
G2533SR	Pressure Gauge	1.5	2.46	62	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	63	500	50	200	3,000	5	G	50	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Back side
Enerpac G2534SR	Pressure Gauge	1.5	2.46	62	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	63	1000	100	400	6,000	10	G	100	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Back side
Enerpac G2535SL	Pressure Gauge	-	3.66	93	1.23	31	-	-	2.50	63	-	SAE No. 4	SAE No. 4	-	2000	100	700	10,000	10	G	200	Pressure gauge	SAE No. 4	Gauge	Glycerine Filled	Underside
